【AWSハンズオン】第12回 CI/CDパイプライン構築

今回作業対象のブランチ

前提条件

• 第1回から第11回までの構築が完了していること
• CI/CD対象のGitHubリポジトリが作成されていること
• こちらからDockerコンテナでの実行環境が準備できていること

Terraform実行環境の起動

前回と同様に、Dockerコンテナ内で作業を進めます。

# コンテナを起動してbashに入る
docker-compose run --rm terraform

これ以降のコマンドは、すべてこのコンテナ内で実行します。

基礎知識

CI/CD（Continuous Integration/Continuous Deployment）は、コード変更を自動的にビルド・テスト・デプロイする仕組みです。

WEBアプリケーション開発者の視点から見ると

ローカル開発では、コードを変更したら手動でビルドし、テストを実行し、サーバーにデプロイします。しかし、チーム開発や本番環境では以下の課題があります。

GitHub Actionsの仕組み

GitHub Actionsは、GitHubが提供するCI/CDサービスです。リポジトリ内にワークフローファイルを配置するだけで動作します。

デプロイ戦略

セキュリティの考慮事項

今回作成するリソース

Terraformコードの実装

変数の追加

CI/CD関連の変数を追加します。

# terraform/variables.tf に追加

# CI/CD関連
variable "enable_github_oidc" {
  description = "GitHub Actions OIDCを有効にするか"
  type        = bool
  default     = true
}

variable "artifact_retention_days" {
  description = "build artifact の保持期間"
  type        = number
  default     = 30
}

variable "github_repository" {
  description = "GitHubリポジトリ（例: username/repository-name）"
  type        = string
  default     = ""
}

GitHub Actions用IAMロール（OIDC）

アクセスキーを使わず、OIDCで安全に認証します。

# terraform/cicd.tf

# GitHub OIDC Provider
resource "aws_iam_openid_connect_provider" "github" {
  url = "https://token.actions.githubusercontent.com"

  client_id_list = [
    "sts.amazonaws.com"
  ]

  # GitHub OIDCプロバイダーのサムプリント
  thumbprint_list = [
    "6938fd4d98bab03faadb97b34396831e3780aea1",
    "1c58a3a8518e8759bf075b76b750d4f2df264fcd"
  ]

  tags = {
    Name = "${var.project_name}-${var.environment}-github-oidc"
  }
}

# GitHub Actions用IAMロール
resource "aws_iam_role" "github_actions" {
  count = var.enable_github_oidc ? 1 : 0

  name = "${var.project_name}-${var.environment}-github-actions"

  assume_role_policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Effect = "Allow"
        Principal = {
          Federated = aws_iam_openid_connect_provider.github.arn
        }
        Action = "sts:AssumeRoleWithWebIdentity"
        Condition = {
          StringEquals = {
            "token.actions.githubusercontent.com:aud" = "sts.amazonaws.com"
          }
          StringLike = {
            # GitHubリポジトリを指定
            "token.actions.githubusercontent.com:sub" = "repo:${var.github_repository}:*"
          }
        }
      }
    ]
  })

  tags = {
    Name = "${var.project_name}-${var.environment}-github-actions"
  }
}

OIDC設定パラメータの説明

デプロイ用IAMポリシー

GitHub Actionsに必要な権限を付与します。

# terraform/cicd.tf

# GitHub Actions用のIAMポリシー
resource "aws_iam_role_policy" "github_actions" {
  count = var.enable_github_oidc ? 1 : 0

  name = "${var.project_name}-${var.environment}-github-actions-policy"
  role = aws_iam_role.github_actions[0].id

  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      # ECR関連の権限
      {
        Effect = "Allow"
        Action = [
          "ecr:GetAuthorizationToken",
          "ecr:BatchCheckLayerAvailability",
          "ecr:GetDownloadUrlForLayer",
          "ecr:BatchGetImage",
          "ecr:PutImage",
          "ecr:InitiateLayerUpload",
          "ecr:UploadLayerPart",
          "ecr:CompleteLayerUpload"
        ]
        Resource = [
          aws_ecr_repository.app.arn,
          "${aws_ecr_repository.app.arn}/*"
        ]
      },
      {
        Effect = "Allow"
        Action = [
          "ecr:GetAuthorizationToken"
        ]
        Resource = "*"
      },
      # ECS関連の権限
      {
        Effect = "Allow"
        Action = [
          "ecs:UpdateService",
          "ecs:DescribeServices",
          "ecs:DescribeTasks",
          "ecs:ListTasks",
          "ecs:RegisterTaskDefinition",
          "ecs:DescribeTaskDefinition"
        ]
        Resource = "*"
      },
      # S3関連の権限（フロントエンド用）
      {
        Effect = "Allow"
        Action = [
          "s3:PutObject",
          "s3:PutObjectAcl",
          "s3:GetObject",
          "s3:DeleteObject",
          "s3:ListBucket"
        ]
        Resource = [
          aws_s3_bucket.frontend.arn,
          "${aws_s3_bucket.frontend.arn}/*"
        ]
      },
      # CloudFront関連の権限
      {
        Effect = "Allow"
        Action = [
          "cloudfront:CreateInvalidation"
        ]
        Resource = aws_cloudfront_distribution.frontend.arn
      },
      # IAM PassRole権限（ECSタスク実行用）
      {
        Effect = "Allow"
        Action = [
          "iam:PassRole"
        ]
        Resource = [
          aws_iam_role.ecs_execution_role.arn,
          aws_iam_role.ecs_task_role.arn
        ]
      }
    ]
  })
}

# ECRへのプッシュ権限
resource "aws_iam_role_policy" "github_actions_ecr" {
  count = var.enable_github_oidc ? 1 : 0

  name = "${var.project_name}-${var.environment}-github-ecr"
  role = aws_iam_role.github_actions[0].id

  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Effect = "Allow"
        Action = [
          "ecr:GetAuthorizationToken",
          "ecr:BatchCheckLayerAvailability",
          "ecr:GetDownloadUrlForLayer",
          "ecr:BatchGetImage",
          "ecr:PutImage",
          "ecr:InitiateLayerUpload",
          "ecr:UploadLayerPart",
          "ecr:CompleteLayerUpload"
        ]
        Resource = [
          aws_ecr_repository.app.arn,
          "${aws_ecr_repository.app.arn}/*"
        ]
      },
      {
        Effect = "Allow"
        Action = [
          "ecr:GetAuthorizationToken"
        ]
        Resource = "*"
      }
    ]
  })
}

# ECSデプロイ権限
resource "aws_iam_role_policy" "github_actions_ecs" {
  count = var.enable_github_oidc ? 1 : 0

  name = "${var.project_name}-${var.environment}-github-ecs"
  role = aws_iam_role.github_actions[0].id

  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Effect = "Allow"
        Action = [
          "ecs:UpdateService",
          "ecs:DescribeServices",
          "ecs:DescribeTaskDefinition",
          "ecs:RegisterTaskDefinition",
          "ecs:ListTaskDefinitions",
          "ecs:DescribeClusters"
        ]
        Resource = [
          aws_ecs_cluster.main.arn,
          aws_ecs_service.app.id,
          "arn:aws:ecs:${var.aws_region}:*:task-definition/${var.project_name}-${var.environment}-app:*"
        ]
      },
      {
        Effect = "Allow"
        Action = [
          "iam:PassRole"
        ]
        Resource = [
          aws_iam_role.ecs_execution_role.arn,
          aws_iam_role.ecs_task_role.arn
        ]
      }
    ]
  })
}

# S3とCloudFrontデプロイ権限
resource "aws_iam_role_policy" "github_actions_frontend" {
  count = var.enable_github_oidc ? 1 : 0

  name = "${var.project_name}-${var.environment}-github-frontend"
  role = aws_iam_role.github_actions[0].id

  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Effect = "Allow"
        Action = [
          "s3:PutObject",
          "s3:PutObjectAcl",
          "s3:GetObject",
          "s3:DeleteObject",
          "s3:ListBucket"
        ]
        Resource = [
          aws_s3_bucket.frontend.arn,
          "${aws_s3_bucket.frontend.arn}/*"
        ]
      },
      {
        Effect = "Allow"
        Action = [
          "cloudfront:CreateInvalidation"
        ]
        Resource = aws_cloudfront_distribution.frontend.arn
      }
    ]
  })
}

IAMポリシー権限の説明

アーティファクト保存用S3バケット

ビルド結果を保存するバケットを作成します。

# terraform/cicd.tf

# アーティファクト保存用S3バケット
resource "aws_s3_bucket" "artifacts" {
  bucket        = "${var.project_name}-${var.environment}-artifacts"
  force_destroy = true

  tags = {
    Name = "${var.project_name}-${var.environment}-artifacts"
  }
}

# バケットの暗号化
resource "aws_s3_bucket_server_side_encryption_configuration" "artifacts" {
  bucket = aws_s3_bucket.artifacts.id

  rule {
    apply_server_side_encryption_by_default {
      sse_algorithm = "AES256"
    }
  }
}

# ライフサイクルポリシー
resource "aws_s3_bucket_lifecycle_configuration" "artifacts" {
  bucket = aws_s3_bucket.artifacts.id

  rule {
    id     = "delete-old-artifacts"
    status = "Enabled"

    filter {}

    expiration {
      days = var.artifact_retention_days
    }
  }
}

Parameter Store

環境変数を安全に管理します。

# terraform/cicd.tf

# デプロイ設定をParameter Storeに保存
resource "aws_ssm_parameter" "ecr_repository_url" {
  name  = "/${var.project_name}/${var.environment}/ecr-repository-url"
  type  = "String"
  value = aws_ecr_repository.app.repository_url

  tags = {
    Name = "${var.project_name}-${var.environment}-ecr-url"
  }
}

resource "aws_ssm_parameter" "ecs_cluster_name" {
  name  = "/${var.project_name}/${var.environment}/ecs-cluster-name"
  type  = "String"
  value = aws_ecs_cluster.main.name

  tags = {
    Name = "${var.project_name}-${var.environment}-ecs-cluster"
  }
}

resource "aws_ssm_parameter" "ecs_service_name" {
  name  = "/${var.project_name}/${var.environment}/ecs-service-name"
  type  = "String"
  value = aws_ecs_service.app.name

  tags = {
    Name = "${var.project_name}-${var.environment}-ecs-service"
  }
}

出力の追加

# terraform/outputs.tf に追加

# CI/CD関連の出力
output "github_actions_role_arn" {
  description = "GitHub Actions用IAMロールARN"
  value       = var.enable_github_oidc ? aws_iam_role.github_actions[0].arn : ""
}

output "artifacts_bucket_name" {
  description = "アーティファクト保存用S3バケット名"
  value       = aws_s3_bucket.artifacts.id
}

GitHub Actionsワークフローの作成

今回はdevelopブランチに、dev環境としてデプロイするように整備していきます。
自身もAIに手伝ってもらいつつCI/CDを書いたので、各々の環境に合わせて試行錯誤してみてください。

サンプルコード

バックエンドAPI用ワークフロー

テストは書いていないので一旦コメントアウトです。

https://github.com/Yutahhhhh/aws-hands-on/blob/tf-dev/.github/workflows/backend-deploy.yml

# .github/workflows/backend-deploy.yml

name: Backend Deploy

on:
  push:
    branches:
      - develop
    paths:
      - 'backend/**'
      - '.github/workflows/backend-deploy.yml'
  workflow_dispatch:

env:
  AWS_REGION: ap-northeast-1
  PROJECT_NAME: ${{ vars.PROJECT_NAME }}
  ENVIRONMENT: dev

permissions:
  id-token: write
  contents: read

jobs:
  # test:
  #   runs-on: ubuntu-latest
  #   steps:
  #     - uses: actions/checkout@v4

  #     - name: Setup pnpm
  #       uses: pnpm/action-setup@v4
  #       with:
  #         version: 9

  #     - name: Setup Node.js
  #       uses: actions/setup-node@v4
  #       with:
  #         node-version: '20'
  #         cache: 'pnpm'
  #         cache-dependency-path: backend/pnpm-lock.yaml

  #     - name: Install dependencies
  #       working-directory: backend
  #       run: pnpm install --frozen-lockfile

  #     - name: Run tests
  #       working-directory: backend
  #       run: pnpm test

  #     - name: Run linter
  #       working-directory: backend
  #       run: pnpm run lint

  build-and-push:
    # needs: test
    runs-on: ubuntu-latest
    outputs:
      image-uri: ${{ steps.image.outputs.uri }}
    steps:
      - uses: actions/checkout@v4

      - name: Configure AWS credentials
        uses: aws-actions/configure-aws-credentials@v4
        with:
          role-to-assume: ${{ secrets.AWS_ROLE_ARN }}
          role-session-name: github-actions
          aws-region: ${{ env.AWS_REGION }}

      - name: Login to Amazon ECR
        id: login-ecr
        uses: aws-actions/amazon-ecr-login@v2

      - name: Set up Docker Buildx
        uses: docker/setup-buildx-action@v3

      - name: Docker meta
        id: meta
        uses: docker/metadata-action@v5
        with:
          images: ${{ steps.login-ecr.outputs.registry }}/${{ env.PROJECT_NAME }}-${{ env.ENVIRONMENT }}-app
          tags: |
            type=ref,event=branch
            type=sha,prefix={{date 'YYYYMMDD'}}-

      - name: Extract single image URI
        id: image
        run: |
          # 最初のタグを取得（通常はsha形式のタグ）
          IMAGE_URI=$(echo "${{ steps.meta.outputs.tags }}" | head -n1)
          echo "uri=${IMAGE_URI}" >> $GITHUB_OUTPUT

      - name: Build and push Docker image
        uses: docker/build-push-action@v5
        with:
          context: backend
          push: true
          tags: ${{ steps.meta.outputs.tags }}
          cache-from: type=gha
          cache-to: type=gha,mode=max
          platforms: linux/amd64

  deploy:
    needs: build-and-push
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Configure AWS credentials
        uses: aws-actions/configure-aws-credentials@v4
        with:
          role-to-assume: ${{ secrets.AWS_ROLE_ARN }}
          role-session-name: github-actions
          aws-region: ${{ env.AWS_REGION }}

      - name: Get current task definition
        run: |
          aws ecs describe-task-definition \
            --task-definition ${{ env.PROJECT_NAME }}-${{ env.ENVIRONMENT }}-app \
            --query taskDefinition > task-definition.json

      - name: Update task definition
        id: task-def
        uses: aws-actions/amazon-ecs-render-task-definition@v1
        with:
          task-definition: task-definition.json
          container-name: ${{ env.PROJECT_NAME }}-${{ env.ENVIRONMENT }}-app
          image: ${{ needs.build-and-push.outputs.image-uri }}

      - name: Deploy to ECS
        uses: aws-actions/amazon-ecs-deploy-task-definition@v1
        with:
          task-definition: ${{ steps.task-def.outputs.task-definition }}
          service: ${{ env.PROJECT_NAME }}-${{ env.ENVIRONMENT }}-app-service
          cluster: ${{ env.PROJECT_NAME }}-${{ env.ENVIRONMENT }}-cluster
          wait-for-service-stability: true

フロントエンド用ワークフロー

テストは書いていないので一旦コメントアウトです。

https://github.com/Yutahhhhh/aws-hands-on/blob/tf-dev/.github/workflows/frontend-deploy.yml

# .github/workflows/frontend-deploy.yml

name: Frontend Deploy

on:
  push:
    branches:
      - develop
    paths:
      - 'frontend/**'
      - '.github/workflows/frontend-deploy.yml'
  workflow_dispatch:

env:
  AWS_REGION: ap-northeast-1
  PROJECT_NAME: ${{ vars.PROJECT_NAME }}
  ENVIRONMENT: dev

permissions:
  id-token: write
  contents: read

jobs:
  # test:
  #   runs-on: ubuntu-latest
  #   steps:
  #     - uses: actions/checkout@v4

  #     - name: Setup Node.js
  #       uses: actions/setup-node@v4
  #       with:
  #         node-version: '20'
  #         cache: 'npm'
  #         cache-dependency-path: frontend/package-lock.json

  #     - name: Install dependencies
  #       working-directory: frontend
  #       run: npm ci

  #     - name: Run tests
  #       working-directory: frontend
  #       run: npm test

  build-and-deploy:
    # needs: test
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Setup pnpm
        uses: pnpm/action-setup@v2
        with:
          version: 8
          run_install: false

      - name: Setup Node.js
        uses: actions/setup-node@v4
        with:
          node-version: '20'
          cache: 'pnpm'
          cache-dependency-path: frontend/pnpm-lock.yaml

      - name: Get pnpm store directory
        shell: bash
        run: |
          echo "STORE_PATH=$(pnpm store path --silent)" >> $GITHUB_ENV

      - name: Setup pnpm cache
        uses: actions/cache@v3
        with:
          path: ${{ env.STORE_PATH }}
          key: ${{ runner.os }}-pnpm-store-${{ hashFiles('frontend/pnpm-lock.yaml') }}
          restore-keys: |
            ${{ runner.os }}-pnpm-store-

      - name: Install dependencies
        working-directory: frontend
        run: pnpm install --frozen-lockfile

      - name: Build application
        working-directory: frontend
        run: pnpm run build

      - name: Configure AWS credentials
        uses: aws-actions/configure-aws-credentials@v4
        with:
          role-to-assume: ${{ secrets.AWS_ROLE_ARN }}
          role-session-name: github-actions
          aws-region: ${{ env.AWS_REGION }}

      - name: Deploy to S3
        run: |
          aws s3 sync frontend/dist s3://${{ env.PROJECT_NAME }}-${{ env.ENVIRONMENT }}-frontend \
            --delete \
            --cache-control "public, max-age=31536000" \
            --exclude "index.html" \
            --exclude "*.json"

          aws s3 cp frontend/dist/index.html s3://${{ env.PROJECT_NAME }}-${{ env.ENVIRONMENT }}-frontend/ \
            --cache-control "public, max-age=300"

      - name: Invalidate CloudFront cache
        run: |
          DISTRIBUTION_ID=$(aws cloudfront list-distributions \
            --query "DistributionList.Items[?Comment=='${{ env.PROJECT_NAME }} frontend distribution'].Id" \
            --output text)

          aws cloudfront create-invalidation \
            --distribution-id $DISTRIBUTION_ID \
            --paths "/*"

Terraform適用用ワークフロー

今回はコードとしてサンプルを用意していませんが、以下のようなコードが想定されると思います。
検証外で、terraformによるリソースの変更が頻繁に変わる場合はCI/CD化しておくと便利です。

# .github/workflows/terraform.yml

name: Terraform

on:
  pull_request:
    paths:
      - 'terraform/**'
      - '.github/workflows/terraform.yml'
  push:
    branches:
      - main
    paths:
      - 'terraform/**'

env:
  AWS_REGION: ap-northeast-1
  TF_VERSION: 1.5.7

permissions:
  id-token: write
  contents: read
  pull-requests: write

jobs:
  plan:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Setup Terraform
        uses: hashicorp/setup-terraform@v3
        with:
          terraform_version: ${{ env.TF_VERSION }}

      - name: Configure AWS credentials
        uses: aws-actions/configure-aws-credentials@v4
        with:
          role-to-assume: ${{ secrets.AWS_ROLE_ARN }}
          role-session-name: github-actions
          aws-region: ${{ env.AWS_REGION }}

      - name: Terraform Init
        working-directory: terraform
        run: terraform init -backend-config=backend.hcl

      - name: Terraform Format Check
        working-directory: terraform
        run: terraform fmt -check

      - name: Terraform Validate
        working-directory: terraform
        run: terraform validate

      - name: Terraform Plan
        id: plan
        working-directory: terraform
        run: terraform plan -no-color -out=tfplan
        continue-on-error: true

      - name: Comment PR
        if: github.event_name == 'pull_request'
        uses: actions/github-script@v7
        with:
          script: |
            const output = `#### Terraform Plan 📖
            \`\`\`
            ${{ steps.plan.outputs.stdout }}
            \`\`\`
            `;
            github.rest.issues.createComment({
              issue_number: context.issue.number,
              owner: context.repo.owner,
              repo: context.repo.repo,
              body: output
            });

  apply:
    if: github.ref == 'refs/heads/main' && github.event_name == 'push'
    needs: plan
    runs-on: ubuntu-latest
    environment: production
    steps:
      - uses: actions/checkout@v4

      - name: Setup Terraform
        uses: hashicorp/setup-terraform@v3
        with:
          terraform_version: ${{ env.TF_VERSION }}

      - name: Configure AWS credentials
        uses: aws-actions/configure-aws-credentials@v4
        with:
          role-to-assume: ${{ secrets.AWS_ROLE_ARN }}
          role-session-name: github-actions
          aws-region: ${{ env.AWS_REGION }}

      - name: Terraform Init
        working-directory: terraform
        run: terraform init -backend-config=backend.hcl

      - name: Terraform Apply
        working-directory: terraform
        run: terraform apply -auto-approve

環境変数の設定

# .env 追記

# GitHubのユーザー名またはOrganization名/GitHubリポジトリ名
TF_VAR_github_repository="ORG/repo"

今回環境変数を設定するため、以下のコマンドで再起動。

# exitで抜けた後に
docker-compose run --rm terraform

リソースを作成

Terraformコンテナ内で以下のコマンドを実行します。

# terraformディレクトリへ移動
cd terraform

# 実行計画の確認
terraform plan

# リソースの作成
terraform apply

GitHubリポジトリの設定

Secretsの設定

GitHubリポジトリの Settings > Secrets and variables > Actions で以下を設定します。

# IAMロールのARNを取得
terraform output github_actions_role_arn

Variablesの設定

GitHubリポジトリの Settings > Secrets and variables > Actions > Variables で設定します。
これはterraformの環境変数(TF_VAR_project_name)で設定しているやつです。

ブランチ保護ルール(推奨)

Settings > Branches で main ブランチの保護ルールを設定します。

動作確認

CI/CDのコードからデプロイされたことを確認したら、ディストリビューションドメイン名(https://d2vxxxxxxxx.cloudfront.net/)からアクセスして確認してみましょう。
基本的にはここでCRUDが機能していればOKです。

デプロイの確認

# ECSタスクの更新確認
aws ecs describe-services \
  --cluster $(terraform output -raw ecs_cluster_id) \
  --services $(terraform output -raw ecs_service_name) \
  --query 'services[0].deployments[*].[status,taskDefinition,desiredCount,runningCount]' \
  --output table

# CloudFront無効化の確認
aws cloudfront list-invalidations \
  --distribution-id $(terraform output -raw cloudfront_distribution_id) \
  --query 'InvalidationList.Items[0:3].[Id,Status,CreateTime]' \
  --output table

ビルドアーティファクトの確認

# S3バケット内のアーティファクト確認
aws s3 ls s3://$(terraform output -raw artifacts_bucket_name)/ --recursive | head -10

トラブルシューティング

OIDC認証エラー

デプロイエラー

コスト管理

開発環境では、以下の方法でコストを削減できます。

# terraform.tfvars
artifact_retention_days = 7  # アーティファクトを7日で削除

次のステップ

次回は、本番運用とスケーリングの設定を行います。

• Terraformコードのモジュール化
• 環境別設定
• Auto Scalingの設定
• RDS Performance Insightsの活用
• 復旧計画の策定
